Black Square Deck Hatch
Frame Material: Aluminium Alloy
Surface: Black Anodized
Glass Material: Smoke Color Acrylic
Handle Material: Nylon
This marine hatch features a black anodized aluminum surface with excellent wear resistance, anti-slip performance, and long-lasting color stability. Built to withstand harsh marine environments, it maintains a sleek, modern appearance, ideal for sport-style boats and dark-colored hulls.
Tested for salt spray and water-tightness and CE certified, it ensures reliable, long-lasting performance and safety.
| BLACK | Frame Size | Cut-out Size | Height | Deck Thickness | ||||
| a | b | c | d | |||||
| MM | In | MM | In | MM | In | MM | In | |
| Square | ||||||||
| 12-01210B | 276x276 | 10.8x10.8 | 211×211 | 8.3x8.3 | 42.5 | 1.8 | 15 | 0.6 |
| 12-01260B | 325x325 | 12.7x12.7 | 260x260 | 10.2x10.2 | 42.5 | 1.8 | 15 | 0.6 |
| 12-01420B | 486x486 | 19.1x19.1 | 421×421 | 16.6x16.6 | 42.5 | 1.8 | 15 | 0.6 |
| 12-01440B | 507x507 | 19.9x19.9 | 442x442 | 17.4x17.4 | 42.5 | 1.8 | 15 | 0.6 |
| 12-01505B | 572x572 | 22.5×22.5 | 507x507 | 20×20 | 42.5 | 1.8 | 15 | 0.6 |
| 12-01600B | 667x667 | 26.2×26.2 | 600x600 | 23.6x23.6 | 42.5 | 1.8 | 15 | 0.6 |
| 12-01627B | 692x692 | 27.2x27.2 | 627x627 | 24.7x24.7 | 42.5 | 1.8 | 15 | 0.6 |
| Rectangular | ||||||||
| 12-01202B | 412x267 | 16.2x10.5 | 347x202 | 13.8×8 | 42.5 | 1.8 | 15 | 0.6 |
| 12-01327B | 522x392 | 20.5x15.4 | 457x327 | 18x12.9 | 42.5 | 1.8 | 15 | 0.6 |
| 12-01377B | 572x442 | 22.5x17.4 | 507x377 | 20x14.8 | 42.5 | 1.8 | 15 | 0.6 |
| 12-01390B | 572x457 | 22.5x17.9 | 507×392 | 20x15.4 | 42.5 | 1.8 | 15 | 0.6 |
